Commentary - Archives of Cancer Biology and Therapy (2020) Volume 1, Issue 3
Can Filtration Technology Advance Culture of Circulating Tumor Cells towards Precision Medicine?
Christoph Müller, Mathias Lindh Jørgensen, Menglin Chen*
Department of Engineering, Aarhus University, Aarhus, Denmark
- *Corresponding Author:
- Menglin Chen
Received date: September 24, 2020; Accepted date: November 05, 2020
Citation: Müller C, Jørgensen ML, Chen M. Can Filtration Technology Advance Culture of Circulating Tumor
Cells towards Precision Medicine?. Arch Cancer Biol Ther. 2020; 1(3): 59-64.
Copyright: © 2020 Müller C, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Expansion of Circulating Tumor Cells (CTC), the metastatic seeds of cancer in the blood stream, holds great potential in clinical
application, especially towards precision medicine. Given the relatively rare nature of CTCs, their culture remains to be a significant
challenge. When developing technologies for CTC culture, there are key elements that need careful consideration, including the speed
of culture, compatibility with downstream analysis, and the implementation of the technology into established clinical daily routines.
Herein, we briefly discuss the implications of our recent report of an ultrathin filter for the capture and culture of circulating colon
Today, cancer is the second leading cause of death, with about 9.6 million deaths globally in 2018 . At the end of the 19th century, Paul Ehrlich contributed a milestone to cancer research by introducing chemotherapy as a promising tumor treatment approach . Since then, cancer treatment has undergone tremendous advances, with chemotherapy still being a widely used cancer treatment method today, however, often associated with severe side effects . Immunotherapy emerged in the 1980’s, and by activating or boosting the body’s own antitumor mechanisms,  it has proven to be one of the most promising cancer treatments, showing fewer off-target effects than chemotherapy . Thanks to advances of the nucleic acid technology, tremendous amount of data can now be collected for each individual patient. Once such data can be properly stratified and related to functional studies, the nucleic acid based technologies will most likely pave the way for early diagnosis and hence allowing cancer treatment in early disease progression [6,7].
In many cases, the cancer heterogeneity counteracts a general treatment approach that benefits every patient to the same extent [8,9]. Precision medicine for cancer is therefore seen as a landmark in cancer therapy. For effective drug testing and down-stream cancer analysis, an ex vivo 3D tumor model comprised of cancer cells from the individual patient would be a valuable tool. One possible resource to obtain ex vivo tumor models from patients might be circulating tumor cells (CTCs). Although CTCs are considered to be the main source of metastasis, their clinical application remain uncertain. Essentially, the CTC number in blood of especially colorectal cancer patients can be extremely low with 10-9 ml?1 among hematologic blood cells . This rareness of CTCs in blood hampers
the efficiency by which they can be analyzed, and used
for functional studies and treatment screening. Several
methods to isolate CTCs from patient blood have been
developed over the last two decades , with CellSearch® as the only FDA approved method to isolate and enumerate CTCs. In recent years, focus has turned from enumeration to expansion of CTCs. The establishment of stable CTC cell lines derived from patient blood has been demonstrated and important insights into cancer biology could be obtained [12-20]. A few leading studies either successfully
applied negative depletion methods [12-14,19,20] or used
microfluidic devices [15-18,21] to culture CTCs from patient
blood. Although highly depending on cancer type and
disease status, negative depletion methods suffer from low
culture success rates (e. g. 5.9% , 8.6% , 8.7%
and 2% ). Since time is precious in cancer treatment,
rapid expansion of captured CTCs is a critical factor for
CTC culture technology. The aforementioned negative
depletion studies showed culture time duration varying
from 3-4 weeks [13,20] to several months [12,14,19] in
order to obtain stable CTC cultures. On the other hand,
microfluidic devices have shown higher culture success rates (e. g. 16.7%  and 19.6–59.3% ), and sufficient
CTC expansion e. g. for drug testing within 2 weeks .
However, microfluidic devices often suffer from their
inherent complexity which hampers their integration into
clinical routines. Thus there is still a need for CTC culture
technologies which enable fast expansion of CTCs and
makes it possible to analyze the expanded tumor material
in a way that can easily adapt to clinical practices.
Electrospinning has been recognized to be a versatile technology to produce unique nanostructures that mimic native extracellular matrix. Together with their high specific surface area, electrospun fibers could not only facilitate the capture but also the on-site culture of CTCs. Several studies have applied electrospinning for capturing CTCs. Ueki et al. developed an anti-EpCAM conjugated solution electrospun polystyrene (PS) mesh. Blood spiked with MCF-7 breast cancer cells was filtered through the PS fibers mesh via vacuum aspiration. Although cell capture was enhanced up to 30% with thickened mesh of 100 um, no further culture of captured cells could be demonstrated . Recently, Liu et al. demonstrated solution electrospun
poly-(lactic-co-glycolic acid) (PLGA) fibers conjugated
with anti-EpCAM and anti-N-Cadherin, for the capture of both epithelial and mesenchymal CTCs . Here, MCF-
7 and GIST882, a gastrointestinal stromal tumor line
representing a more mesenchymal-like cancer cell line,
upon spike-in blood samples were incubated on top of
the fibers for 40 min before immunochemistry. A capture
efficiency of 60% could be achieved, however, without
further culture of captured cells . Xu et al. developed
a microfluidic chip incorporated with hyaluronic acid
functionalized electrospun PLGA fibers, able to isolate
CD44 positive cancer cells. Additionally, it was shown that
in principle captured cells could also be cultured directly
on the device. However, an extremely high cancer cell
concentration of 100,000 cells/ml, not clinical relevant,
was used for perfusion culture experiments and no patient
derived blood was used in this study. Culture under static
conditions was demonstrated with 7000 HeLa cells per
well. Possibly, culture experiments with lower cancer cell
concentrations were also conducted, however, no clinical
relevant cancer cell concentration for culture is clearly
Advancing electrospinning with computer aided design additive technology, melt electrospinning written (MEW) of polymer melts with lower conductivity is distinguished by its robustness to produce tailored porosity, mechanical property, and transparency which facilitate both filtration and on-site cell culture/monitoring/down-stream analysis. Recently, our group firstly demonstrated a MEW fabricated polycaprolactone (PCL) filter conjugated with anti-EpCAM antibodies for the purpose of capturing and in situ expansion of epithelial CTCs . We have shown, that as few as 20 HT29 colon cancer cells spiked into 4 ml (5 cells per ml) of whole blood can be captured and expanded in situ to tumor bodies visible to the naked eye within two weeks that can be microscopically monitored on-site followed with down-stream genomic/proteomic analysis. In perspective, this approach could facilitate precision medicine for cancer patients, by providing a platform for capture of CTCs from patient blood and further on-site culture to create cancer clusters within 2-4 weeks. Figure 1 illustrates the potential workflow and how the filter could be implemented in clinic, leading to a more individualized cancer treatment. We demonstrate, that our filter is highly compatible with down-stream analysis on both protein and nucleic acid level. The filter is only 10 μm thick, has a porosity of 60%, and immunochemistry-based analysis of the filtered cells is straightforward.
Challenges and Future Outlook
Through tremendous efforts, technologies to isolate CTCs from patient blood samples for ex vivo culture have been developed. For all the technologies there is a tradeoff between capture efficiency and purity, which appears to be almost inversely related. Furthermore, it is a major challenge to make devices that allow for efficient capture and at the same time present an environment for the tumor cells where they will proliferate. Finally, the technology needs to be compatible with microscopy as this allows monitoring the capture and culture on-site. Microscopy is also a key step in the pathological analysis of the cancer disease. The characterization by immunochemistry is still and probably will continue to be a very important ground for the clinical treatment decision making. Indeed, the access to the tumor material after culture is one of the great advantages of the filter compared to some of the recently reported elegant microchip systems for CTC expansion [26,27].
One of the main arguments for choosing a filtration setup to expand CTCs, is the apparent simplicity of implementing the technology into the clinic. Filtration setups are intuitively easy to understand, and filtrations can be done in any standard laboratory facilities and do not require highly trained laboratory staff. Furthermore, our MEW fabricated filter profits from its low cost in production. MEW is a stable and cost-effective method to print PCL microfibers. The equipment necessary to conduct the filtration can be found in most laboratories (tubes, syringes and syringe pump). The simplicity of the filtration setup together with the on-site culture/ monitoring/downstream analysis features stand out in comparison to multicomponent microfluidic devices [21,28].
A filter such as the one reported herein can enable both affinity and size-based capture of CTCs. Indeed, by being able to tune pore sizes, flow dynamics, and the number of different conjugated antibodies, a broader range of CTCs can be captured [11,29,30]. Furthermore, although suggested to facilitate cancer cluster formation , too high amounts of WBCs might decrease the CTC culture efficiency. Hence, aiming for a pore size distribution allowing more WBC to pass the filter pores while maintaining a high CTC capture efficiency could increase chances to successfully expand captured CTCs. WBCs are known to be less stiff due to lower N/C ratio compared to CTCs  and might be able to be pushed through the
smaller pores by a higher flowrate.
Clearly the culture conditions for captured CTCs will have a major impact on the ability of CTCs to proliferate and form clusters. It is known that not all CTCs have the potential to proliferate to form new cancerous colonies, since some CTCs might lack proliferative features and maintain in a state of dormancy without cancer outgrowth, or are simply dead . Dormant CTCs might require external signals for further proliferation like growth factors and cytokines . Among those, hypoxia has been reported to play a role as an external signal for cancer outgrowth, where cancer cells become more invasive and tend to more metastatic behavior . It has been reported that hypoxia can act
as an external cue stimulating dormant cells to exhibit a more stem cell-like phenotype and ultimately leading to
cancer outgrowth . Erler et al. showed the importance
of hypoxia in establishing a premetastatic niche where
CTCs might reside and form a metastatic colony .
Since oxygen levels in outgrowing tumors can reach below
2%, future culture experiments under hypoxia condition
could mimic the hypoxic environment the captured CTC
might originate from .
However, the interplay between CTC dormancy and hypoxia remains elusive , and CTCs have been successfully cultured under both hypoxic [13,15] and nonhypoxic condition . A few other studies suggest that hypoxia might act suppressive on CTCs in dormant states. It has been shown that the hypoxia-inducible gene domain family member 1A (HIGD1A), a hypoxia induced survival factor, can also promote a state of dormancy in cancer cells . Additionally, a study by Hofstetter et al. suggested that hypoxia is increasing protein phosphatase 2A activity, a factor important for cell cycle regulation and growth inhibition .
Culture under low attachment and low serum levels  has been suggested to be essential for successful culture, whereas others suggest co-culture  to be an important parameter. This underscores that there might not be onefits- all standard for culturing these very heterogenous cancer cells.
Our technology of capturing and culturing CTCs using melt electrowritten filter will be validated by patientderived blood samples. If successful, we have developed a platform for CTC isolation and rapid ex vivo cultivation, which allows many crucial downstream analysis methods, and can be easily implemented in established clinical routines.
